STANDARD SPECIFICATIONS
GVWR: 25,750 lbs.
Empty Weight: 5,750 lbs.
Maximum Payload: 20,000 lbs. w/ adequate hitch load
Overall Length: 32′ 9″
Deck Length: 25′ (20′ Flat w/ 5′ Beavertail)
Overall Width: 96″
Deck Width: 96″
Deck Height: 35″
Beavertail: 5′ Cleated
Ramps: 5′ Cleated
Hitch: Adjustable 2 1/2″ Eye
Hitch Height: 22″ – 31″
Tongue: Cold Form w/ Tool Tray
Axles: (2) 10K Oil Bath w/Brakes
Suspension: Multi-Leaf Spring
Brakes: Electric / Self Adjust 12 1/4″ x 3 3/8″ w/ Break-a-way
Wheels: 16″ x 6″ Single 8-bolt
Tires: 7.50 x 16LT (Bias)
Jack Capacity: 12,000 lb. drop foot
Main Frame: 10″ Channel @ 15.3#
Crossmembers: 3″ channel @ 7# 18″ OC
Side Rail: 6″ channel @ 8.2#
Decking: 2″ X 8″ Treated Pine
Tie Downs: Stake Pockets
Lights: DOT Approved Lighting
Colors: Yellow or Black
